CHAMPIONS® PRO Cylinder
CHAMPIONS® PRO uses shaped pin encryption (+ - x /), to protect duplicates.
- Body and rotor are protected against drilling (hardened steel pins, spheres, pins and caps).
- 6 coding pins including pins and counter-pins with anti-pick shaping in hardened steel.
- Aligned and shaped upper profile control pins which in the event of picking or bumping irreversibly block the cylinder, preventing the opening.
- 3 side profile control pins.
- All thumb turn cylinders or knob provisioned cylinders are supplied with emergency function.
- The package includes cylinder, ownership card, 3/5 keys, assembly instructions and fixing screw. To guarantee maximum security, the keys and ownership card are sealed at the origin.
- Certified for resistance to “BUMPING” and “PICKING”, they bear the acronym “BKC” on the label.
- Resistant to "TRACING", the key tracing technique, they bear the acronym "TRC" on the label.
- The A2P version can be supplied subject to use on the combined Mottura A2P locks.
- Brushed nickel-plated finish. Brushed brass finish on request
- ICIM and A2P* certified.
Features
-
Made in Italy
-
“MM” profile key
-
"Mathematical" shaped controls
-
Anti snap shear
-
30° off-centered cam rest position
-
NO Bumping/Picking
-
NO Tracing
-
Construction key
-
SET&RESET version
-
VARIO version (3 levels)
-
Master key
Duplication only by Authorized Centers
Champions® PRO key duplication is allowed at Authorized Centers and MOTTURA CLUB upon presentation of the owner's card, which comes out with each set of original keys: the numbers printed on the card corresponds to the numbers printed on the keys.
A network of specialized duplication centers called CENTRI PRO MOTTURA can provide a faster duplicate.
For the protected files and personalized package, the key duplication is RESERVED to the customer/dealer or its subsidiaries.
Anti-bumping
Resistant to cylinder percussion attacks.
Anti-picking
Resistant to break-in attempts with a pick-lock tool.
Anti-tracing
Protection against key forgery attempts.
Anti-snap
Designed in such a way that, in the event of an attempt to break it with an iron rod, the cylinder breaks at a specific point.
Cylinder types
CHAMPIONS® PRO cylinders are available in 6 different types.
Double cylinder
Frictioned upon request (it opens from the outside even if a key is inserted from the inside).
Double cylinder with adjustable knob provision
Knob fixing ø 8 mm.
Double cylinder with knob provision
Knob fixing ø 8 mm.
Thumb turn cylinder
Knob fixing ø 8 mm
Removable knobHalf cylinder
For locks with 14/20 mm thickness
Half cylinder for armoured doors
For 30mm thicnkness locks
Documentation
Increase the protection of your cylinder
Install a Mottura Defender® to increase the safety of your cylinder. Mottura Defender® is a protection for the European cylinder. Such protections are sophisticated and active mechanisms against break-in attempts, with attention to every detail.
